In the design of ultra-precision equipment motion platforms, friction is a core obstacle restricting positioning accuracy and repeat positioning stability. No matter how the preload and lubrication are optimized for mechanically contacted guideways, contact friction still exists between metals. Crawling effect easily occurs during start and stop. Tiny friction directly interferes with nano-scale positioning. The granite air bearing guideway base combines the natural low-expansion material advantage of stone with the air bearing suspension principle, forming a nearly contactless and nearly frictionless motion system. It serves as the core motion reference for semiconductor, precision laser and high-precision inspection equipment.
Many equipment manufacturers treat the air bearing structure and base material separately, assuming that qualified air pads alone can deliver stable frictionless motion. In fact, if the base substrate suffers poor thermal stability, micro-deformation caused by ambient temperature fluctuation will directly change the air film gap, resulting in local variation of air film thickness. The suspension state is disrupted, and implicit contact friction appears, invalidating the frictionless motion designed originally. The thermal expansion performance of material is the underlying prerequisite for the air bearing system to maintain frictionless state for a long time.
UNPARALLELED Group (Brand: UNPARALLELED®) fully leverages the natural low-expansion characteristics of UNPARALLELED® black granite in the R&D and manufacturing of granite air bearing guideway bases, forming a synergistic effect with air bearing technology instead of simply stacking the two. This dense black granite features uniform crystal structure and ultra-low thermal expansion coefficient. When temperature changes, the overall deformation of the substrate is uniform and minimal, without local warping or concave-convex deformation. When the temperature of workshop environment fluctuates, the flatness of the guideway working surface can remain stable. The micron-scale gap between air pads and granite reference surface will not be distorted, continuously maintaining a uniform suspended air film, preventing contact between air pads and base working surface and preserving the foundation of frictionless motion.
The core principle of air bearing is to lift moving components completely by high-pressure air forming a uniform air film between the base working surface and air pads, eliminating direct solid contact so as to remove solid friction. However, the air film is extremely sensitive. Even micron-scale deformation of the base may reduce local gaps and cause scratching friction. The UNPARALLELED® granite substrate goes through complete aging and stress relief treatment to release latent internal stress of stone. The reference surface will not creep and deform slowly under long-term load cycles and alternating temperature changes. The working surface is finished with ultra-precision manual lapping by veteran craftsmen to achieve continuous and uniform nano-level flatness. It ensures consistent air film thickness across the whole travel range of movement, so moving assemblies can stay suspended throughout the full stroke without sudden change of local friction resistance.
Another value brought by the material's low-expansion property is consistent motion accuracy. During long continuous operation, continuous heat generation from linear motors and optical modules brings local temperature rise. Ordinary base materials produce uneven deformation after heating, deteriorating guideway straightness and fluctuating air film gaps. Motion resistance becomes unstable and the positioning trajectory drifts. The low-expansion property of UNPARALLELED granite suppresses such thermally induced deformation. The suspension status of the air bearing system is free from interference of local temperature rise. During high-speed scanning and reciprocating motion, the platform maintains nearly constant low resistance, delivering smoother motion response without hysteresis and backslash error caused by mechanical friction.
This combined solution of material and air bearing also greatly reduces heat generation during platform movement. Friction of traditional mechanical guideways continuously generates frictional heat, which in turn deforms the base, forming a vicious cycle: friction generates heat → base deformation → precision drift. The nearly frictionless granite air bearing guide produces almost no frictional heat during movement. Coupled with granite's excellent thermal stability, this negative cycle is cut off. This feature is especially critical for optical inspection, laser processing and semiconductor XY motion platforms with long continuous scanning. It guarantees stable platform trajectory during long running hours and prevents measurement and processing data from drifting with operation time.
In manufacturing, UNPARALLELED implements integrated design for low-expansion substrate and air bearing structure. Air channel layout and air pad mounting references are directly machined on the granite body to avoid hidden stress and deformation risks brought by split assembly. Every base is finished with lapping, air channel machining and air bearing linkage test in constant-temperature, constant-humidity and dust-free workshops. A full set of traceable measuring instruments are adopted to verify air film uniformity over the full travel, confirming that the platform can maintain smooth frictionless motion under temperature fluctuation conditions.
Of course, nearly frictionless does not mean zero friction. Weak viscous resistance from air viscosity exists inside the air film, which belongs to fluid resistance and is essentially different from solid contact friction. This kind of resistance brings almost no wear, no crawling effect and no friction dust, which is also an important reason why granite air bearing bases are widely adopted in clean semiconductor workshops.
In summary, nearly frictionless motion cannot be achieved merely by air bearing structure. The granite substrate with natural low expansion serves as the cornerstone for stable operation of air bearing systems. The UNPARALLELED® granite air bearing guideway base relies on the stable reference surface of low-expansion black granite, matched with precisely designed air bearing suspension system. Moving assemblies are always lifted by air film to eliminate solid contact friction, delivering smooth motion with low hysteresis and long-term stability, meeting strict nano-scale motion control requirements of various high-end ultra-precision equipment.
